Product List

Harvest Frost Alarm Systems

Pre-Configured Systems:

	Frost Alarm including two standard wireless temperature sensors and a long range wireless temperature sensor
	Frost Alarm - With basic Weather Sensors including a standard wireless temperature sensor, long range wireless temperature sensor, temperature/humidity sensor, rain gauge, and wind speed/direction
	Frost Alarm - With Weather Sensors and Soil Monitoring including a standard wireless temperature sensor, two long range wireless temperature sensor, multi input transmitter, Decagon soil moisture, temperature/humidity sensor, rain gauge, and wind speed/direction

The above units are examples only as the exact configuration is specified by the customer when order is placed. Options can be fitted at a later date if required.

Sensors Available:

(for available product information click the image)

	Wireless Short Range Remote (SRR) Range of up to 300m
	Multi Input Wireless Long Range Remote (LRR) Range of up to 2km, G2 Systems only, used for monitoring multiple types of sensors
	Rain Gauge Davis 0.2mm tip
	Wind Speed/Direction Sensor Davis
	Wind Speed/Direction Split Sensors Tru Track
	Temperature/Humidity Sensor Used to calculate dew point and wet bulb
	Combined Air Temperature/Relative Humidity/Barometric Pressure Sensor
	Soil Moisture Probe Decagon 10HS Sample size of just under 1 litre
	Soil Moisture/Temperature Probe Aquaflex SI.99 Sampling area of over 6 litres
	Multi Level Soil Moisture Probe Sentek EasyAg 30 or 50 Samples at either 3 or 5 levels 10cm apart, low impact installation
	Leaf Wetness Sensor Decagon Used to calculate Bacchus Botrytis risk
	Soil Temperature Sensor Calibrated by Harvest to 0.1°C
	Water Temperature Sensor Calibrated by Harvest to 0.1°C
	Solar Radiation sensor Davis Used to calculate Evapotranspiration
	UV Sensor Davis Used to calculate UV index
	Submerisable Pressure Sensor PMC VL4000 series for water level monitoring, 19mm diameter, Titanium casing, suitable for most wells/bores
	Ultrasonic Sensor BannerT30Ux series Used for open channel weir depth gauging - robust and accurate
	Pipe Pressure Sensor Gems Pressure ranges, casing and signal output all customisable

Operating Charge:

The annual charge covers cellular data charges, alarm messages, lifetime base system warranty, and website charges.

Cellular Frost System: 10 minute logging with hourly reporting 1 minute logging and reporting under alarm conditions

Upgrades:

Please contact us for upgrade options.

Harvest Farm and Irrigation Monitors

	Mains Powered Non-Weather Proof Systems Wall mount, mains powered, backup battery and splash proof powder coated steel enclosure
	Basic Non-Wireless System Ability to monitor up to two flow meters and depth sensor or pressure sensor
	Advanced G2 Non-Wireless System Ability to monitor up to eight flow meters and up to eight depth or pressure sensors SDI-12 input and dual relay ouptuts
	Advanced G2 Wireless System Ability to monitor up to eight flow meters and up to eight depth or pressure sensors SDI-12 input, dual relay output plus both standard and long range wireless capabilities
	Solar Powered Weather Proof Systems Solar Powered with waterpoof stainless steel casing with 2" pipe mount bracket
	Basic Non-Wireless System Ability to monitor up to two flow meters and depth sensor or pressure sensor
	Advanced G2 Non-Wireless System Ability to monitor up to eight flow meters and up to eight depth or pressure sensors SDI-12 input and dual relay ouptuts
	Advanced G2 Wireless System Ability to monitor up to eight flow meters and up to eight depth or pressure sensors SDI-12 input, dual relay output plus both standard and long range wireless capabilities

Sensors:

	Multi Input Wireless Long Range Remote (LRR) Range of up to 2km, G2 Systems only, used for monitoring multiple types of sensors
	Rain Gauge Davis 0.2mm tip
	Wind Speed/Direction Sensor Davis
	Wind Speed/Direction Split Sensors Tru Track
	Temperature/Humidity Sensor Used to calculate dew point and wet bulb
	Combined Air Temperature/Relative Humidity/Barometric Pressure Sensor
	Soil Moisture Probe Decagon 10HS Sample size of just under 1 litre
	Soil Moisture/Temperature Probe Aquaflex SI.99 Sampling area of over 6 litres
	Multi Level Soil Moisture Probe Sentek EasyAg 30 or 50 Samples at either 3 or 5 levels 10cm apart, low impact installation
	Leaf Wetness Sensor Decagon Used to calculate Bacchus Botrytis risk
	Soil Temperature Sensor Calibrated by Harvest to 0.1°C
	Water Temperature Sensor Calibrated by Harvest to 0.1°C
	Solar Radiation sensor Davis Used to calculate Evapotranspiration
	UV Sensor Davis Used to calculate UV index
	Submerisable Pressure Sensor PMC VL4000 series for water level monitoring, 19mm diameter, Titanium casing, suitable for most wells/bores
	Ultrasonic Sensor BannerT30Ux series Used for open channel weir depth gauging - robust and accurate
	Pipe Pressure Sensor Gems Pressure ranges, casing and signal output all customisable

All systems (apart from the limited input monitor) are compatable with all weather sensors listed above.

Operating Charges:

	Cellular Operation Includes 10 minute logging, lifetime base system warranty, data transfer and website costs
	Satellite Operation Custom logging intervals, lifetime base system warranty, data transfer and website costs

Harvest Weather Stations

All systems come standard in industrial stainless steel weather proof enclosure with solar panel and battery. A Temperature/Humidity sensor comes standard with all systems. Systems can be mounted via a 2" water pipe or warratah mounting bracket for quick and easy deployment.

	Standard Weather Station Davis Wind Sensor, Davis Rain Gauge
	Industrial Weather Station Vaisala Wind Sensor, Hydrological Services Rain Gauge
	Industrial Weather Station Vaisala Ultrasonic Wind Sensor, Hydrological Services Rain Gauge
	Industrial Weather Station Vaisala WXT520
	Satellite Operation Iridium satellite operation can be added to any of the weather station packages

Other system packages are available, please contact us for options or a quote. Sensor specs can be found here. All systems are also capable of monitoring third party sensors or devices. Alarms can also be setup for most monitored variables.
If required automatic data push of any or all monitored variables can be arranged - standard formats are CSV and XML.

Additional Sensors

	Soil Moisture probe Decagon 10HS Sample size of just under 1 litre
	Soil Moisture/Temperature probe Aquaflex SI.99 High end sensor with a sampling area of over 6 litres
	Multi Level Soil Moisture probe Sentek EasyAg 30 or 50 Samples at either 3 or 5 levels 10cm apart, low impact installation
	Leaf Wetness sensor Decagon LW1 Used to calculate Bacchus Botrytis risk
	Solar Radiation sensor Davis 6450 Used to calculate Evapotranspiration
	UV sensor Davis 6490 Used to calculate UV index
	Soil Temperature sensor Calibrated by Harvest to 0.1°C
	Water Temperature sensor Calibrated by Harvest to 0.1°C
	Road Temperature sensor Calibrated by Harvest to 0.1°C, enclosed in brass casing
	Rail Track Temperature sensor Calibrated by Harvest to 0.1°C
	Submerisable water depth pressure sensor PMC VL4000 series 19mmm diameter with Titanium casing, fully subermsible, suitable for most wells/bores
	Ultrasonic sensor Banner T30U and T30Ux series Used for stream and weir depth gauging - robust and accurate
	Pipe pressure sensor Gems series Pressure ranges, casing and signal output customisable

Operating Charges:

	Cellular Operation Includes 10 minute logging, lifetime base system warranty*, data transfer and website costs
	Satellite Operation Custom logging intervals, lifetime base system warranty*, data transfer and website costs

*please contact us for information concerning sensor warranty terms

Harvest Telemetry Products

	Serial Port Extender (SPE G2)
	Industrial Telemetry Unit (ITU G2)
	Rain Gauge Monitor
	Blast Gas Monitor
	Multipurpose Wastewater Monitor
	DTMF Remote Controller
	Level Crossing Monitor

Cellular Modules

	Telit G24 GPRS/EDGE OEM modules
	Telit H24 GPRS/3G OEM modules
	Telit G30 GPRS/EDGE OEM modules

Please click here for a full range of modules.

Other Harvest Products

	Telit Roadstar 2g/3G Car Phone with GPS Contact us for more info
	Harvest Trailer Safety Chain Lock Wholesale enquiries welcome

Please contact us for volume pricing or more information.
